Overview

Framing Insulation Board

iBOARD F12 rigid insulation (Formerly called Insulboard) is a framing insulation board composed of a closed-cell thermoset polyisocyanurate foam core with two reflective foil facings. Tested in accordance with AS/NZ standards to comply with BCA/NCC requirements, iBOARD F12 rigid insulation is manufactured using blowing agents that are CFC/HCFC-free and have zero Ozone Depletion Potential (ODP). Providing higher R-values from less thickness iBOARD F12 rigid insulation allows for reduced wall system depth while giving the required thermal performance making it the instinctive option for all wall lining and framing applications.




Excellent Thermal Performance

iBOARD F12 rigid insulation provides excellent thermal properties with one of the lowest thermal conductivity ratings of any insulation material on the market at 0.022 W/mK.

Fire Testing

iBOARD F12 rigid insulation meets or exceeds all mandatory standards of the NCC/BCA and is therefore suitable for all applications including cavities, concrete wall framing and soffits.

Environmentally Friendly

iBOARD F12 rigid insulation is manufactured with a CFC/HCFC free blowing agent with Zero Ozone Depletion Potential (ODP) for a greener future.

Proven Performance

Used widely for all framing on projects throughout Western Australia, iBOARD F12 rigid insulation can be specified and used with complete confidence.

BCA Compliant

iBOARD F12 rigid insulation is compliant with relevant Australian standards, giving confidence to builders and contractors for suitability in all framing applications.

Fibre-free material

Composed of a uniform closed-cell polyisocyanurate foam core with two foil facings, iBOARD F12 rigid insulation is non-irritant to the skin and non-allergenic.

Versatile Applications

Easy and effective when installed between studs and lining for timber and steel frame wall constructions iBOARD F12 rigid insulation is ideal where cavity depth is restricted.

More Cost Effective

Due to superior manufacturing technology and large volume production, iBOARD F12 rigid insulation is a more cost effective high R-value insulation than other alternatives.

Sizes

Framing Insulation Board

Code R-value

Description

Availability

MOQ

IBF272312 R1.23

iBOARD 27mm Rigid Insulation, 2270 x 1200mm

Stock

1 Board

IBF372312 R1.68 iBOARD 37mm Rigid Insulation, 2270 x 1200mm Stock 1 Board
IBF472312 R2.14 iBOARD 47mm Rigid Insulation, 2270 x 1200mm Stock 1 Board
IBF572312 R2.59 iBOARD 57mm Rigid Insulation, 2270 x 1200mm Stock 1 Board
ITR4850 NA INSULTAPE 48mm Reinforced Foil Tape, 50m Roll Stock 1 Roll



Technical Data

Test Item

Standard

Result
Thermal Conductivity W/mK 0.022
Emittance Actual Low
Ignitability AS 1530.3 0
Flame Spread AS 1530.3 0
Heat Release AS 1530.3 0
Smoke Development AS 1530.3 2
Fire Performance Evaluation CertMark Group 1
Tensile Strength Perpendicular to Faces EN 1607 80 kPa
Compressive Strength EN 826 >110 kPa
Compressive Strength at 10% Deformation EN 826 > 150 kPa



Specify

Draft Specification

iBOARD F12 Specification – Framed Walls and Internal Wall Lining

Product: iBOARD F12
Application: Rigid frame and internal wall insulation
Project: ________________________________

Insulation:
The wall framing Insulation shall be iBOARD F12____ mm thick, with a thermal value of R____, composed of a closed-cell CFC/HCFC-free and zero Ozone Depletion Potential (ODP) rigid thermoset polyisocyanurate foam core with two reflective gastight 50 µm aluminium foil facings, tested in accordance with AS/NZ standards to comply with BCA/NCC and manufactured by BLUECHIP (Phone: 08 9451 2344).

Fire Properties:
In accordance with AS 1530.3, iBOARD F12 rigid insulation achieves the following results:

• Ignitability: 0
• Flame spread: 0
• Heat evolved: 0
• Smoke development: 2

Download iBOARD F12 Framing Board Specification
