Terracotta Cladding System
ARGETON terracotta cladding tiles are manufactured in Germany by the Wienerberger Corporation, who are the largest clay block, brick and roof tile manufacturers in the world. Enriching new and modern buildings, ARGETON terracotta cladding also imparts an exclusive contemporary character to refurbished properties. Combined with steel, wood or glass, it is elegant, natural and looks effective for decades. The high strength of the ARGETON terracotta cladding and its fixing system make the façade particularly suitable for use on public buildings, e.g. schools, and other high stress areas.
ARGETON terracotta cladding tiles are the first ceramic facade to have passed the test for ball throwing safety in accordance with DIN18632-3.
The high precision dimensioning of ARGETON terracotta cladding tile plates is achieved by a special calibrating facility, the essential element of the precise joints which gives a facade its overall impression.
ARGETON terracotta cladding is a non-combustible facade material that can be used internally or externally wherever a non-combustible material is required.
High Acoustic Rating
The additional noise insulation of the building by the ARGETON terracotta cladding reduces air-carried sound by approx. 9 dB, depending on type of application.
ARGETON terracotta cladding offers a 10 year warranty and is backed by global giant Wienerberger, who are the largest manufacturer of bricks in the world.
Enriching new and refurbished buildings, ARGETON terracotta cladding imparts an exclusive contemporary character to all projects. It is elegant, natural and looks effective for decades.
Concealed Fix System
The high strength of the ARGETON terracotta cladding tiles and its concealed fixing system make the façade particularly suitable for use on public buildings, e.g. schools, and other high stress areas.
Ventilated Facade System
ARGETON terracotta cladding is installed on a ventilated sub-construction system allowing for the building envelope to breathe which increases thermal and energy efficiency.
ARGETON Tampa Tile
150, 175, 187.5 x Max 600mm
200, 212.5, 225 x Max 1200mm
237.5, 243.5, 250, 257, 275, 300, 400, 500 x Max 1500mm
|ARGETON Terzo Tile||
200, 225 x Max 1200mm
243.5 x Max 1500mm
|ARGETON Terzo 1 Tile||150 x Max 600mm||14-16 Weeks||100m2|
|ARGETON Terzo 2 Tile||225 x Max 1200mm||14-16 Weeks||100m2|
|ARGETON Terzo 3 Tile||
225 x Max 1200mm
250 x Max 1500mm
|ARGETON Lineo 4 Tile||
200 x Max 1200mm
257 x Max 1500mm
|ARGETON Lineo 9 Tile||250 x Max 1500mm||14-16 Weeks||100m2|
|ARGETON Danza Tile||200 x Max 1200mm||14-16 Weeks||100m2|
|ARGETON Corner Tile||90, 120 x Max 600mm||14-16 Weeks||100m2|
200, 250, 300 x Max 800mm
|BARRO Square Baguette||50 x 50mm or 69 x 69mm x Max 1500mm||14-16 Weeks||100m2|
|BARRO Elliptical Baguette||150 x 50mm x Max 1500mm||14-16 Weeks||100m2|
|BARRO Rectangle Baguette||100 x 50mm x Max 1200mm||14-16 Weeks||100m2|
TERRACOTTA CLADDING SYSTEM
Design, engineer, supply, fabricate and install ARGETON terracotta cladding system by BLUECHIP (Ph: 08 9451 2344) to the areas as shown on the drawings. The contractor shall provide a complete mechanically fixed system, including cladding tiles, sarking, framing, fixings, sealant and other accessories required. The terracotta product shall be …………………………………………… (nominate Tampa / Terzo / Lineo / Danza / Argelite Tiles and/or Barro baguettes) and the sizes shall be as shown on architectural drawings and installed using the proprietary fixing system as per the manufacturers recommendations. The colour shall be …………………………………………… (nominate a colour/s).
