Overview

Insulated Plasterboard Lining

IBOARD P17 insulated plasterboard is an internal lining product composed of a closed-cell thermoset polyisocyanurate foam core bonded to a 10mm deemed-to-satisfy non-combustible gypsum based plasterboard. Tested in accordance with relevant AS/NZ standards, IBOARD P17 insulated plasterboard provides the highest level group 1 fire rating in accordance with AS 5637*. Unlike alternative products, IBOARD P17 insulated plasterboard offers excellent ageing performance due to its very high moisture resistance and it is 100% formaldehyde free for superior air quality and occupant wellbeing.

Zero Formaldehyde

IBOARD P17 insulated plasterboard contains zero traces of formaldehyde and it is fibre-free making it non-irritant to the skin, non-allergenic and safer compared to other products.

Group 1 Fire Rating*

IBOARD P17 insulated plasterboard has a non-combustible plasterbaord facer which achieves a Group 1 fire rating in accordance with AS 5637 for superior safety and compliance in all internal lining applications.

Superior Ageing Performance

Due to it's outstanding resistance to moisture and excellent compressive strength, IBOARD P17 insulated plasterboard offers much better thermal ageing performance than other products.

100% Non-corrosive

Unlike some other insulation products, IBOARD P17 insulated plasterboard core material is 100% non-corrosive and will not cause corrosion issues if it comes in contact with structural steel or fixings.

Higher R-value

IBOARD P17 insulated plasterboard provides excellent thermal properties with one of the lowest thermal conductivity ratings of any insulation material on the market at 0.022 W/mK.

Environmentally Friendly

IBOARD P17 rigid insulation is manufactured in Europe under strict quality control using only CFC/HCFC free blowing agents which have Zero Ozone Depletion Potential (ODP).

Time & Space Saver

Due to being a 2-in-1 product, IBOARD P17 insulated plasterboard is fast and efficient to install and offers cost and space savings due to its high R-value to thickness ratio.

Micro Cell Technology

IBOARD P17 insulated plasterboard has a much finer cell structure with extremely low water absorbtion compared to other products (<0.6%) so it's R-value is retained long-term and it is rot and mould proof.

*Group 1 fire rating applies to the exposed plasterboard facing in accordance with AS 5637 and NCC 2019 requirements.

Availability

Availability

Code R-value

Description

Lead Time

MOQ
IBP372312 R1.29

IBOARD 37mm P17 Insulation, 2270 x 1200mm

Stock

1 Board
IBP472312 R1.74 IBOARD 47mm P17 Insulation, 2270 x 1200mm Stock 1 Board
IBP572312 R2.20 IBOARD 57mm P17 Insulation, 2270 x 1200mm Stock 1 Board
IBP672312 R2.65 IBOARD 67mm P17 Insulation, 2270 x 1200mm Stock 1 Board
IBP772312 R3.11 IBOARD 77mm P17 Insulation, 2270 x 1200mm Stock 1 Board
IBP872312 R3.56 IBOARD 87mm P17 Insulation, 2270 x 1200mm Stock 1 Board
IBP972312 R4.01 IBOARD 97mm P17 Insulation, 2270 x 1200mm Stock 1 Board
IBP1072312 R4.47 IBOARD 107mm P17 Insulation, 2270 x 1200mm Stock 1 Board



Technical Data

Test Item

Standard

 Result
Thermal Conductivity (Insulation) W/mK 0.022*
Thermal Conductivity (Plasterboard) W/mK 0.17*
Spread of Flame Index AS 1530.3 0**
Smoke Developed Index AS 1530.3 3**
Group Rating AS 5637 Group 1**
Average Specific Extintion Area m2/kg <250**
Smoke Growth Rate (SMOGRA) m2/s2x1000 <100**
Compressive Strength EN 826 >110 kPa
Compressive Strength at 10% Deformation EN 826 >150 kPa



*Material R-values are calculated based on the insulation thickness at 0.022 W/mK in addition to the 10mm plasterboard at 0.17W/mK. **Fire testing applies to the exposed compliant plasterboard facing.

Gallery

IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17 IBOARD P17

Downloads

  • This email address is being protected from spambots. You need JavaScript enabled to view it.
  • This email address is being protected from spambots. You need JavaScript enabled to view it.
  • This email address is being protected from spambots. You need JavaScript enabled to view it.
  • This email address is being protected from spambots. You need JavaScript enabled to view it.
  • CAD Install Details
  • Testing & Certification
