Overview

Prefinished Fibre Cement Panel

ULTRAPEARL prefinished fibre cement (Formerly Vitrafinish) is a 9mm prefinished CFC fibre cement facade panel which is prefinished with a highly durable factory applied 2-pack fluoropolymer paint system in unlimited colours and installed to a steel framing system with colour matched screws or rivets. It can be supplied cut-to-size and offers all the benefits of the raw fibre cement board such as impact resistance and non-combustibility. ULTRAPEARL prefinished fibre cement is proudly manufactured in Australia and provides building owners with outstanding life-cycle cost savings and a 15 year coating warranty.


V700 Fluoropolymer

The ULTRAPEARL prefinished fibre cement coating has a unique thermosetting factory finish that withstands long-term exposure to extreme climate conditions providing lifetime resilience.


Acoustic Rated

ULTRAPEARL prefinished fibre cement has high acoustic ratings which enhances sound proofing for buildings such as airports, public train stations, schools, universities and hospitals.


Graffiti Resistant

ULTRAPEARL prefinished fibre cement is graffiti and chemical resistant allowing quick and easy removal without harming the coating. An ideal solution for educational and public area buildings.


Cut to Size

ULTRAPEARL prefinished fibre cement is supplied cut to size for fast installation once onsite. All edges receive the same high quality coating as the surface receives.


Unlimited Custom Colours

Along with our huge range of standard colours, ULTRAPEARL prefinished fibre cement can be supplied in any custom colour that suits your project. The limit is your imagination.


15 Year Warranty

ULTRAPEARL prefinished fibre cement is so confident in the superior quality of its paint system it offers a 15 year coating warranty for peace of mind and guaranteed quality.


Proven Performance

The coating system used on ULTRAPEARL prefinished fibre cement has been used on facades through-out Australia and the world for decades. Specify ULTRAPEARL with 100% confidence.


Non-combustible

ULTRAPEARL prefinished fibre cement is a non-combustible facade material that can be used internally or externally wherever a non-combustible material is required in accordance with BCA/NCC.




Finishes

UP9701 White Pearlcoat
UP9701 White Pearlcoat
UP9003 Sandblasted Silver
UP9003 Sandblasted Silver
UP6805 Light Sage
UP6805 Light Sage
UP9001 Champagne
UP9001 Champagne
UP9005 Medium Bronze
UP9005 Medium Bronze
UP9602 Light Copper
UP9602 Light Copper
UP9702 Emperors Gold
UP9702 Emperors Gold
UP6706 Tangerine
UP6706 Tangerine
UP9002 Mineshaft
UP9002 Mineshaft
UP3401 Atlantis Blue
UP3401 Atlantis Blue
UP9016 Traffic White
UP9016 Traffic White
UP9003 Signal White
UP9003 Signal White
UP9010 Pure White
UP9010 Pure White
UP1013 Oyster White
UP1013 Oyster White
UP1015 Light Ivory
UP1015 Light Ivory
UP1014 Ivory
UP1014 Ivory
UP1001 Beige
UP1001 Beige
UP1011 Brown Beige
UP1011 Brown Beige
UP7035 Light Grey
UP7035 Light Grey
UP9006 White Aluminium
UP9006 White Aluminium
UP7004 Signal Grey
UP7004 Signal Grey
UP7001 Silver Grey
UP7001 Silver Grey
UP7015 Slate Grey
UP7015 Slate Grey
UP7016 Anthracite Grey
UP7016 Anthracite Grey
UP9004 Signal Black
UP9004 Signal Black
UP9005 Jet Black
UP9005 Jet Black
UP6037 Pure Green
UP6037 Pure Green
UP6029 Mint Green
UP6029 Mint Green
UP6003 Olive Green
UP6003 Olive Green
UP6005 Moss Green
UP6005 Moss Green
UP5021 Water Blue
UP5021 Water Blue
UP5015 Sky Blue
UP5015 Sky Blue
UP5002 Ultramarine Blue
UP5002 Ultramarine Blue
UP5011 Steel Blue
UP5011 Steel Blue
UP3015 Light Pink
UP3015 Light Pink
UP4003 Heather Violet
UP4003 Heather Violet
UP3027 Raspberry Red
UP3027 Raspberry Red
UP3028 Pure Red
UP3028 Pure Red
UP3020 Traffic Red
UP3020 Traffic Red
UP3005 Wine Red
UP3005 Wine Red
UP4007 Purple Violet
UP4007 Purple Violet
UP4012 Pearl Blackberry
UP4012 Pearl Blackberry
UP1016 Sulfur Yellow
UP1016 Sulfur Yellow
UP1018 Zinc Yellow
UP1018 Zinc Yellow
UP1023 Traffic Yellow
UP1023 Traffic Yellow
UP1005 Honey Yellow
UP1005 Honey Yellow
UP1017 Saffron Yellow
UP1017 Saffron Yellow
UP2003 Pastel Orange
UP2003 Pastel Orange
UP2005 Luminous Orange
UP2005 Luminous Orange
UP2002 Vermilion
UP2002 Vermilion
UP8000 Green Brown
UP8000 Green Brown
UP8008 Olive Brown
UP8008 Olive Brown
UP8014 Sepia Brown
UP8014 Sepia Brown
UP8016 Mahogany Brown
UP8016 Mahogany Brown
Unlimited Custom Colours
Unlimited Custom Colours

Availability

Product Range

ULTRAPEARL
Metallic Colours
ULTRAPEARL
Solid Colours
STUDTEK
Joint Top-hat
STUDTEK
Intermediate Top-hat
STUDTEK
Backing Strip



Availability

Description

Sheet Sizes

Lead Time

MOQ

ULTRAPEARL Standard Sizes

1800, 2400, 3000 x 900mm

1800, 2400, 2700, 3000 x 1200mm

3-5 Weeks

1 Sheet

ULTRAPEARL Custom Shapes & Sizes

Up to 3000 x 1200mm

4-6 Weeks

1 Sheet

ULTRAPEARL Custom Colours

Up to 3000 x 1200mm

4-6 Weeks

1 Sheet



Accessories

Code

Description

Lead Time

MOQ

SG1203560 STUDTEK 120 x 35mm Joint Top-hat, 6.0m Length Stock 1 Length
SG503560 STUDTEK 50 x 35mm Intermediate Top-hat, 6.0m Length Stock 1 Length
SZA757560 STUDTEK 75 x 75mm Zincalume Corner Angle, 6.0m Stock 1 Length
SJS359 STUDTEK 67 x 3.5mm Black Backing Strip, 3.59m Length Stock 1 Length
SJS299 STUDTEK 67 x 3.5mm Black Backing Strip, 2.99m Length Stock 1 Length
SCC60 STUDTEK 35 x 35mm Zincalume Cavity Closer, 6.0m Length Stock 1 Length
SCC48 STUDTEK 35 x 35mm Black Cavity Closer, 4.8m Length Stock 1 Length
TFG4032 STUDTEK 40 x 3.2mm EPDM Vertical Joint Gasket, 25m Roll Stock 1 Roll
UPWFR30 ULTRAPEARL 30mm x 10-16 Wafer Screw (Insert Colour), 1000 Pack 3-5 Weeks 1 Pack
UPFW ULTRAPEARL 8mm Nylon Facade Washer, 1000 Pack Stock 1 Pack



Systems Components

FIRESPAN
AS 1530.1 Sarking
SINIAT BOARD
Rigid Air Barrier
STUDTEK
Cladding Top-hats
ADHESIVES
SikaTack & 11FC
FASTENERS
Cladding Fixings
